Create openSUSE images for Arm/RISC-V boards by avicenzi

Project Description

Create openSUSE images (or test generic EFI images) for Arm and/or RISC-V boards that are not yet supported.

Goal for this Hackweek

Create bootable images of Tumbleweed for SBCs that currently have no images available or are untested.

Consider generic EFI images where possible, as some boards can hold a bootloader.

Document in the openSUSE Wiki how to flash and use the image for a given board.

Boards that I have around and there are no images:

• Rock 3B
• Nano PC T3 Plus
• Lichee RV D1
• StartFive VisionFive (has some image needs testing)

Hack Week 22

• NanoPC T4

Hack Week 21

• NanoPi M4B
• Radxa Zero

Resources

• https://en.opensuse.org/Portal:Arm
• https://en.opensuse.org/Portal:RISC-V

---

RISC-V emulator in GLSL capable of running Linux by favogt

Description

There are already numerous ways to run Linux and some programs through emulation in a web browser (e.g. x86 and riscv64 on https://bellard.org/jslinux/), but none use WebGL/WebGPU to run the emulation on the GPU.

I already made a PoC of an AArch64 (64-bit Arm) emulator in OpenCL which is unfortunately hindered by a multitude of OpenCL compiler bugs on all platforms (Intel with beignet or the new compute runtime and AMD with Mesa Clover and rusticl). With more widespread and thus less broken GLSL vs. OpenCL and the less complex implementation requirements for RV32 (especially 32bit integers instead of 64bit), that should not be a major problem anymore.

Goals

Write an RISC-V system emulator in GLSL that is capable of booting Linux and run some userspace programs interactively. Ideally it is small enough to work on online test platforms like Shaderoo with a custom texture that contains bootstrap code, kernel and initrd.

Minimum:

riscv32 without FPU (RV32 IMA) and MMU (µClinux), running Linux in M-mode and userspace in U-mode.

Stretch goals:

FPU support, S-Mode support with MMU, SMP. Custom web frontend with more possibilities for I/O (disk image, network?).

Resources

RISC-V ISA Specifications
Shaderoo
OpenGL 4.5 Quick Reference Card

Result as of Hackweek 2024

WebGL turned out to be insufficient, it only supports OpenGL ES 3.0 but imageLoad/imageStore needs ES 3.1. So we switched directions and had to write a native C++ host for the shaders.

As of Hackweek Friday, the kernel attempts to boot and outputs messages, but panics due to missing memory regions.

Since then, some bugs were fixed and enough hardware emulation implemented, so that now Linux boots with framebuffer support and it's possible to log in and run programs!

The repo with a demo video is available at https://github.com/Vogtinator/risky-v

---

FizzBuzz OS by mssola

Project Description

FizzBuzz OS (or just fbos) is an idea I've had in order to better grasp the fundamentals of the low level of a RISC-V machine. In practice, I'd like to build a small Operating System kernel that is able to launch three processes: one that simply prints "Fizz", another that prints "Buzz", and the third which prints "FizzBuzz". These processes are unaware of each other and it's up to the kernel to schedule them by using the timer interrupts as given on openSBI (fizz on % 3 seconds, buzz on % 5 seconds, and fizzbuzz on % 15 seconds).

This kernel provides just one system call, write, which allows any program to pass the string to be written into stdout.

This project is free software and you can find it here.

Goal for this Hackweek

• Better understand the RISC-V SBI interface.
• Better understand RISC-V in privileged mode.
• Have fun.

Resources

• SBI v2.0 ratified specification
• Blog post on SBI
• mssola/fbos

Results

The project was a resounding success Lots of learning, and the initial target was met.

---

Tumbleweed on Mars-CM (RISC-V board) by ph03nix

RISC-V is awesome, Tumbleweed is awesome, chocolate cake is awesome. I'm planning to combine all of them in one project.

Project Description

I recently purchased a MILK-V Mars CM and managed to setup it up already using Debian Linux. My project for this Hackweek is to see how far I can get to run Tumbleweed on this compute module board.

Goal for this Hackweek

• Run Tumbleweed on the Compute Module

Resources

• http://milkv.io/mars-cm
• https://en.opensuse.org/HCL:VisionFive2

---

Investigate Milk-V Jupiter board (riscv64) by a_faerber

Description

On Monday of Hackweek 24 we received two Milk-V Jupiter mini-ITX boards (JUPITER_V1.1) via the RISC-V International devboards program. The Jupiter board uses a Spacemit M1 System-on-Chip (SoC).

The Banana Pi BPI-F3 board with related Spacemit K1 SoC had previously already been investigated by Marvin Friedrich.

Goals

Investigate the hardware, any shipping boot firmware and its ability to boot openSUSE Tumbleweed.

Resources

• Milk-V Jupiter product page
• Milk-V Jupiter docs

Progress

• On Monday Andreas purchased an ATX power supply, to power up the board.
• According to UART output (note there's two UART pinouts on the board), there appears to be an undocumented U-Boot bootloader in QSPI, in addition to the documented microSD, NVMe and eMMC boot methods.
• The on-board bootloader does not seem to support USB ("No working controllers found").
• Manually loading our GRUB from microSD (via load+bootefi commands from SPI-based U-Boot) works, but in GRUB loading our kernel fails ("error: ../../grub-core/loader/efi/linux.c:521:out of memory.").
• Marvin instead had success flashing a ready-made Bianbu OS image via titantools to microSD card (i.e., a different U-Boot on microSD), that he then modified to load openSUSE kernels instead.

---
